Technical Specification
Nominal Voltage..............................................................................12V (6 cells per unit)
Nominal Capacity(20°C)
20hour rate(0.1A,10.8V).................................................................................2.3Ah
10hour rate(0.19A,10.8V)................................................................................1.9Ah
5hour rate(0.36A,10.5V)................................................................................1.8Ah
1hour rate(1.33A,9.6V)................................................................................1.33Ah
Dimension(mm).................................................................L178 x W35 x H61 x TH67mm
Approx. Weight ......................................................................................0.92kg (2.03lbs)
Terminal Type...............................................................................................................F1
Internal Resistance..............................................................40mΩ(fully Charged @20°C)
Max.Charge Current................................................................................................0.69A
Max.Discharge Current (5s).......................................................................................30A
Ambient Temperature
Discharge....................................................................................................-15-45°C
Charge........................................................................................................-15-45°C
Storage.......................................................................................................-15-45°C
Capacity Affected by Temp.(10 hr capacity)
105% @40°C
100%@25°C
85%@0°C
65%@-15°C
Self-Discharge @20°C..................................................................Approx. 3% per month
Charge Voltage @20~25°C
Float charge voltage.............................................................................13.6V-13.8V
Equalize Charge Voltage......................................................................14.4V-14.9V
Dimensions
Performance Characteristics
Battery Discharge
Battery Construction
Product specifications are subject to change without further notice.
