Portable 12V dc mini UPS 8800mAh for router

Built—in lithium battery

lntelligent circuit design with over charging, over-discharging and short circuit protection

DC 5v/9V/12v output voltage selectable

Customized products of various capacities

Router/VOIP Phone System Surveillance Systems/ Modem/Security Systems

Return Prev

Technical Specification

Model	DC1018P	DC1036P
Input	85-265Vac/50-60Hz
Output	USB 5V/2A	USB 5V/2A
	DC 5V/2A	DC 5V/2A
	DC 9V/1A	DC 9V/2A
	DC 12V/1A	DC 12V/2A
	POE 15V/0.6A	POE 15V/1A
	POE 24V/0.6A	POE 24V/1A
Output power(Max.)	18W	36W
Quantity & Capacity of battery	2200mAh*4(Lithium battery)
Operate temperature	-10℃ - 40℃
Humidity	10%-90%RH
Dimension(mm)	16010533mm
Net weight(kg)	0.41kg	0.42kg

DC mini UPS 12V from Andes Power 222.jpg

DC UPS-04.jpg

Product specifications are subject to change without further notice.
